The FusionServer 2288H V6 is a 2U 2-socket rack server with flexible configurations, which can be widely used for cloud computing, virtualization, database, and big data workloads. The 2288H V6 can be configured with 2-socket Intel® Xeon® Scalable processors, 32 DDR4 RAM, 14 PCIe expansion slots, and supports large local storage resources.
It integrates patented technologies such as DEMT, intelligent power consumption management, FDM intelligent fault management, and optional FusionDirector full lifecycle management software, which can effectively reduce operations cost, improve return on investment.
| Server Model | FusionServer 2288H V6 |
| Form Factor | 2U rack server |
| Processors | One or two 3rd Gen Intel® Xeon® Scalable Ice Lake processors (8300/6300/5300/4300 series), TDP up to 270 W |
| Local Storage | Supports various drive configurations: 8-31 x 2.5-inch SAS/SATA/SSD, 12-20 x 3.5-inch SAS/SATA, 4/8/16/24 NVMe SSDs, 45 x 2.5-inch drives or 34 full-NVMe SSDs. Supports Dual M.2 SSDs. |
| RAID support | Supports RAID 0, 1, 10, 1E, 5, 50, 6, or 60, optional supercapacitor for cache data power failure protection. |
| Network | Provides expansion capability of multiple types of networks; Supports OCP 3.0 NICs. |
| PCIe Expansion | Maximum of fourteen PCIe 4.0 slots. |
| Management | iBMC chip integrates management functions (fault diagnosis, automated O&M). Supports Redfish, SNMP, IPMI 2.0. |
| Operating Systems | Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle, Ubuntu, Debian, etc. |
| Power Supply | Two hot-swappable PSUs in 1+1 redundancy mode. Supports various configurations from 900W to 3000W. |
